Daikin FTKS50GVMV - Remove Indoor Heat Exchanger

Si041255EH Indoor Heat Exchanger
Removal Procedure 15
5 Slightly pull out the
auxiliary piping.
6 Unfasten the 2 hooks
on the left side.
7 Push the 2 hooks on
the right side and
unfasten them.
8 Pull the indoor heat
exchanger to the front
side and unfasten the
hooks completely, and
then lift the indoor heat
exchanger.
Step Procedure Points
(R11367)
Auxiliary piping
Hook
(R17680)
Hook
(R13517)
(R17681)
Indoor heat exchanger
