Daikin FTXR-T Series User Manual

Capacity Tables EDUS041820
14 Split Type Air Conditioners FTXR-T Series
7. Capacity Tables
FTXR09TVJUW + RX09RMVJU9
FTXR09TVJUS + RX09RMVJU9
60 Hz, 208 V
Cooling
Heating
AFR 7.7
BF 0.16
Temp: Celsius
TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 10 20 30 35 40 46
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.020.02.531.900.342.531.900.532.461.860.752.341.800.812.211.740.872.071.670.94
16.022.03.072.070.512.831.950.632.581.830.752.461.780.812.331.720.872.191.660.95
18.025.03.192.150.512.952.040.642.701.930.762.581.880.822.461.830.882.311.760.95
19.426.73.252.260.523.012.150.642.762.040.76
2.64 1.99 0.82 2.52 1.94 0.88 2.37 1.88 0.95
22.030.03.442.160.523.192.070.642.951.980.762.821.930.822.701.890.882.551.840.96
24.032.03.562.100.533.312.010.653.071.930.772.941.890.832.821.850.892.671.800.96
Temp: Fahrenheit
TC, SHC: kBtu/h
PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 50 68 86 95 104 115
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.268.08.626.470.348.626.470.538.396.350.757.976.150.817.555.940.877.055.700.94
60.8 71.6 10.48 7.06 0.51 9.64 6.66 0.63 8.80 6.26 0.75 8.39 6.07 0.81 7.97 5.87 0.87 7.46 5.65 0.95
64.4 77.0 10.90 7.34 0.51 10.06 6.96 0.64 9.22 6.59 0.76 8.80 6.41 0.82 8.38 6.23 0.88 7.88 6.02 0.95
67.0 80.0 11.10 7.69 0.52 10.27 7.33 0.64 9.43 6.97 0.76
9.00 6.80 0.82 8.59 6.63 0.88 8.08 6.42 0.95
71.6 86.0 11.73 7.39 0.52 10.89 7.06 0.64 10.05 6.75 0.76 9.63 6.60 0.82 9.21 6.44 0.88 8.71 6.26 0.96
75.2 89.6 12.14 7.17 0.53 11.30 6.87 0.65 10.46 6.59 0.77 10.05 6.45 0.83 9.63 6.31 0.89 9.12 6.14 0.96
AFR 9.8
Temp: Celsius
TC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB –15 –10 –5 0 6 10 18
°C TC PI TC PI TC PI TC PI TC PI TC PI TC PI
15.0 1.40 0.53 1.68 0.56 1.96 0.59 2.25 0.61 3.04 0.72 3.31 0.74 3.84 0.79
21.1 1.31 0.55 1.60 0.57 1.88 0.60 2.16 0.63
2.94 0.73 3.21 0.76 3.74 0.81
22.0 1.28 0.55 1.56 0.58 1.84 0.61 2.13 0.63 2.90 0.74 3.16 0.76 3.70 0.81
24.0 1.24 0.56 1.53 0.58 1.81 0.61 2.09 0.64 2.86 0.75 3.12 0.77 3.66 0.82
25.0 1.23 0.56 1.51 0.59 1.79 0.61 2.07 0.64 2.84 0.75 3.10 0.77 3.64 0.82
27.0 1.19 0.57 1.48 0.59 1.76 0.62 2.04 0.65 2.80 0.76 3.06 0.78 3.59 0.83
Temp: Fahrenheit
TC: kBtu/h
PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB 5 14 23 32 43 50 64
°F TC PI TC PI TC PI TC PI TC PI TC PI TC PI
59.0 4.78 0.53 5.74 0.56 6.70 0.59 7.67 0.61 10.38 0.72 11.28 0.74 13.10 0.79
70.0 4.48 0.55 5.45 0.57 6.41 0.60 7.37 0.63
10.00 0.73 10.94 0.76 12.75 0.81
71.6 4.37 0.55 5.33 0.58 6.29 0.61 7.25 0.63 9.89 0.74 10.80 0.76 12.61 0.81
75.2 4.25 0.56 5.21 0.58 6.17 0.61 7.14 0.64 9.75 0.75 10.66 0.77 12.47 0.82
77.0 4.19 0.56 5.15 0.59 6.11 0.61 7.08 0.64 9.69 0.75 10.59 0.77 12.40 0.82
80.6 4.07 0.57 5.03 0.59 6.00 0.62 6.96 0.65 9.55 0.76 10.45 0.78 12.27 0.83
