Daikin FTXR-T Series User Manual

EDUS041820 Capacity Tables
Split Type Air Conditioners FTXR-T Series 17
FTXR12TVJUW + RX12RMVJU9
FTXR12TVJUS + RX12RMVJU9
60 Hz, 208 V
Cooling
Heating
AFR 9.5
BF 0.19
Temp: Celsius
TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 10 20 30 35 40 46
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.020.03.012.260.323.012.260.523.012.260.823.012.261.002.972.241.162.672.091.17
16.022.03.862.560.553.792.530.843.462.371.003.302.291.083.132.211.162.822.071.17
18.025.04.282.790.693.952.630.853.622.481.013.462.411.093.292.331.172.962.191.17
19.426.74.362.900.694.032.760.853.702.611.01
3.54 2.54 1.09 3.38 2.47 1.17 3.04 2.33 1.17
22.030.04.612.780.694.282.650.863.952.521.023.782.461.103.622.401.183.252.261.17
24.032.04.772.700.704.442.570.864.112.461.023.952.401.103.782.341.183.392.211.17
Temp: Fahrenheit
TC, SHC: kBtu/h
PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 50 68 86 95 104 115
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 10.26 7.70 0.32 10.26 7.70 0.52 10.26 7.70 0.82 10.26 7.70 1.00 10.12 7.63 1.16 9.11 7.13 1.17
60.8 71.6 13.17 8.75 0.55 12.93 8.63 0.84 11.81 8.08 1.00 11.24 7.81 1.08 10.68 7.54 1.16 9.61 7.05 1.17
64.4 77.0 14.61 9.50 0.69 13.49 8.97 0.85 12.36 8.46 1.01 11.80 8.21 1.09 11.24 7.96 1.17 10.11 7.47 1.17
67.0 80.0 14.89 9.91 0.69 13.77 9.40 0.85 12.64 8.90 1.01
12.00 8.66 1.09 11.52 8.42 1.17 10.36 7.94 1.17
71.6 86.0 15.73 9.50 0.69 14.60 9.04 0.86 13.48 8.60 1.02 12.91 8.39 1.10 12.35 8.18 1.18 11.09 7.71 1.17
75.2 89.6 16.28 9.20 0.70 15.16 8.78 0.86 14.03 8.38 1.02 13.47 8.19 1.10 12.91 7.99 1.18 11.58 7.55 1.17
AFR 11.2
Temp: Celsius
TC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB –15 –10 –5 0 6 10 18
°C TC PI TC PI TC PI TC PI TC PI TC PI TC PI
15.0 1.89 0.80 2.27 0.84 2.65 0.88 3.03 0.92 4.10 1.08 4.45 1.12 5.17 1.19
21.1 1.77 0.82 2.15 0.86 2.53 0.91 2.91 0.95
3.96 1.11 4.32 1.14 5.03 1.22
22.0 1.72 0.83 2.10 0.87 2.48 0.91 2.86 0.96 3.91 1.12 4.26 1.15 4.98 1.23
24.0 1.68 0.84 2.06 0.88 2.44 0.92 2.82 0.96 3.85 1.13 4.21 1.16 4.92 1.24
25.0 1.65 0.85 2.03 0.89 2.41 0.93 2.79 0.97 3.82 1.13 4.18 1.17 4.90 1.24
27.0 1.61 0.85 1.99 0.90 2.37 0.94 2.75 0.98 3.77 1.14 4.13 1.18 4.84 1.25
Temp: Fahrenheit
TC: kBtu/h
PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB 5 14 23 32 43 50 64
°F TC PI TC PI TC PI TC PI TC PI TC PI TC PI
59.0 6.43 0.80 7.73 0.84 9.03 0.88 10.33 0.92 13.98 1.08 15.20 1.12 17.64 1.19
70.0 6.04 0.82 7.33 0.86 8.63 0.91 9.93 0.95
13.50 1.11 14.73 1.14 17.17 1.22
71.6 5.88 0.83 7.18 0.87 8.47 0.91 9.77 0.96 13.32 1.12 14.55 1.15 16.99 1.23
75.2 5.72 0.84 7.02 0.88 8.31 0.92 9.61 0.96 13.14 1.13 14.36 1.16 16.80 1.24
77.0 5.64 0.85 6.94 0.89 8.24 0.93 9.53 0.97 13.05 1.13 14.27 1.17 16.71 1.24
80.6 5.48 0.85 6.78 0.90 8.08 0.94 9.37 0.98 12.86 1.14 14.08 1.18 16.52 1.25
