Si041137 Removal of Electrical Box
Removal Procedure 13
9
Remove the screw and
detach the earth /
ground wire.
10
Remove the screw of
the electrical box.
11
Unfasten the hook at
the upper far side by
pressing it from above
and pulling the
electrical box.
12
Lift up the electrical box
and pull it out.
î
There is a hook also at the
lower part of the back. When
reassembling the electrical
box, make sure that it is
securely fastened.
Step
Procedure Points
(R16863)
Earth / ground wire
(R3939)
(R8081)
Hook
(R8082)
To Next Page
