Si041137
Removal
of PCBs (Pattern 2)
Remo
val Pr
ocedu
re
21
5
Pull
out the t
erminal
s.
6
Unfasten t
he hooks and
remove the shiel
d plate.
7
Remove the signal
recei
ver PCB. (3 hooks)
8
Disconnect
the
connector
[S48].
[S4
8]: co
ntro
l PCB
Step
Procedure
Points
(R13111)
(R13112)
Shield plate
(R13113)
Signal
receiver PCB
(R13114)
[S48]
22
24
