Indoor Unit : FUD 30/40B (HORIZONTAL AIR DISCHARGE)
All dimensions are in mm
Dimension
Model
ABCDEFGHI JKLMNOPQ
FUD 30B 1540 1370 1600 1640 53 50 20 117 48 754 885 533 474 220 408 222 468
FUD 40B 1540 1370 1600 1640 53 50 20 117 48 754 885 533 474 220 408 222 468
Dimension
Model
RSTUVWXYZZAZBZC
FUD 30B 120 35 88 262 155 132 1040 60 850 130 747 103
FUD 40B 120 35 88 262 155 132 1040 60 850 130 747 103
A
X
ZA
ZY
T
S
K
ZB
ZC
ZS
W
PN
LML
X
Y
RQ U
ZA
Z
S
K
ZB
ZC
Z
S
B
E
H
I
F
J
G
C
D
F
G
V
O
I
T
W
V
NOTE:
FOR HORIZONTAL AIR DISCHARGE
LEFT PIPING (OPTIONAL)
RIGHT PIPING (STANDARD)
