Si241306 Procedure to Remove Suction Grille and Air Filter
Removal Procedure 3
Removing suction grille
1
Remove 2 fixing screws
located at both left and
right sides of suction
grille.
2
Open widely and lift
suction grille to remove
it.
Step
Procedure Points
Suction grille stopper
Screws
