Daikin FVY71LAVE - Procedure to Remove Suction Grille and Air Filter

Procedure to Remove Suction Grille and Air Filter Si241306
2 Removal Procedure
1. Procedure to Remove Suction Grille and Air Filter
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Step
Procedure Points
Removing air filter
1
Pull tabs of suction
grille to open the grille
slightly.
2
Lift up air filter
Air Filter
