SCHALTPLÄNE
(siehe Anlage Schaltpläne)
Tabelle Konfigurationen/Schaltpläne
KONFIG. GERÄT SCHALTPLAN
01-02-03
FWL-M-V FC66002487 [1]
FWB UT66000879 [4]
FWD
UT66000880 [5]
UT66000881 [6]
07-08-09
FWL-M-V FC66002491 [2]
FWB UT66000882 [7]
FWD
UT66000883 [8]
UT66000884 [9]
UT66000885 [10]
UT66000886 [11]
10-11-12
FWL-M-V FC66002487 [1]
FWB UT66000879 [4]
FWD
UT66000880 [5]
UT66000881 [6]
16-17-18
FWL-M-V FC66002491 [2]
FWB UT66000882 [7]
FWD
UT66000883 [8]
UT66000884 [9]
UT66000885 [10]
UT66000886 [11]
19-20-21
FWL-M-V FC66002487 [1]
FWB UT66000879 [4]
FWD
UT66000880 [5]
UT66000881 [6]
25-26-27
FWL-M-V FC66002487 [1]
FWB UT66000879 [4]
FWD
UT66000880 [5]
UT66000881 [6]
31
FWB UT66000882 [7]
FWD
UT66000883 [8]
UT66000884 [9]
UT66000885 [10]
UT66000886 [11]
Tabelle Konfigurationen/Schaltpläne
GERÄT TYP KONFIGURATION SCHALTPLAN
FWL-M-V
- 1-2-3-10-11-12-19-20-21-25-26-27 FC66002487
7-8-9-16-17-18 FC66002491
FWB
- 1-2-3-10-11-12-19-20-21-25-26-27 UT66000879
7-8-9-16-17-18-31 UT66000882
FWD
04/12 1-2-3-10-11-12-19-20-21-25-26-27 UT66000881
7-8-9-16-17-18-31 UT66000884
06/12 3PH 7-8-9-16-17-18-31 UT66000886
16/18 1-2-3-10-11-12-19-20-21-25-26-27 UT66000880
7-8-9-16-17-18-31 UT66000883
16/18 3PH 7-8-9-16-17-18-31 UT66000885
EPIMSB6
FWL-M-V -
FC66002493FWB -
FWD -
