UT66002766-02
All copying, even partial, of this manual is strictly forbidden 9
» 4 pipes
FWP-C 04 05 06 08
Speed
min med max min med max min med max min med max
Declared speed
2,5,7 1,5,7 1,6,7 1,4,7
Control voltage (E) V
2,90 7,90 8,90 4,50 7,30 8,90 4,50 7,40 8,30 5,40 8,30 9,90
Rated air flow (E) m³/h
109 243 270 170 272 336 195 357 398 302 524 642
Available static pressure (E) Pa
10 50 63 19 50 77 19 50 63 17 50 75
Power input (E) W
6 25 32 10 23 39 10 26 35 21 50 77
Maximum current absorption A
0,32 0,60 0,84 0,84
Total cooling capacity (1)(E) kW
0,93 1,74 1,91 1,28 1,93 2,31 1,59 2,72 3,01 1,95 3,22 3,75
Sensible cooling capacity (1)(E) kW
0,62 1,24 1,36 0,90 1,38 1,64 1,09 1,89 2,09 1,47 2,44 2,89
FCEER class (E)
A
Water flow (2) l/h
161 302 333 221 335 404 274 473 522 339 562 656
Water pressure drop (2)(E) kPa
2 5 6 3 6 8 3 7 9 3 8 11
Heating capacity (3)(E) kW
1,14 1,93 2,06 1,55 2,07 2,32 2,09 3,09 3,29 2,80 3,82 4,24
FCCOP class (E)
A
Water flow (3) l/h
100 169 180 136 181 204 183 271 288 245 334 371
Water pressure drop (3)(E) kPa
1 2 3 2 3 3 2 3 4 3 5 6
Standard coil - number of rows
28 49 52 39 50 54 39 50 54 38 52 58
Total sound power level (4) dB(A)
3+1 3+1 4+1 3+1
Inlet + radiated sound power level (4)(E) dB(A)
26 47 50 37 48 52 37 48 52 36 50 56
Outlet sound power level (4)(E) dB(A)
25 46 49 36 47 51 36 47 51 35 49 55
Water content - standard coil dm³
0,47 0,47 0,59 0,59
Cross-section area of power cables (5) mm²
1,00 1,00 1,00 1,00
Power supply cable type
N07V-K
Safety fuse F A
1 1 1 1
Fuses type
gG
FWP-C 10 11 15 17
Speed
min med max min med max min med max min med max
Declared speed
1,6,7 1,6,7 5,6,7 5,6,7
Control voltage (E) V
3,40 7,60 8,50 3,40 7,60 8,50 6,80 7,50 8,30 6,80 7,50 8,30
Rated air flow (E) m³/h
333 683 755 333 683 755 1050 1163 1289 1050 1163 1289
Available static pressure (E) Pa
12 50 61 12 50 61 40 50 60 40 50 60
Power input (E) W
11 54 67 11 54 67 105 128 162 105 128 162
Maximum current absorption A
0,91 0,91 3,52 3,52
Total cooling capacity (1)(E) kW
2,29 4,32 4,72 2,51 4,88 5,32 6,28 6,81 7,38 7,04 7,64 8,28
Sensible cooling capacity (1)(E) kW
1,67 3,19 3,48 1,77 3,43 3,74 4,64 5,03 5,46 4,96 5,38 5,84
FCEER class (E)
A A C B
Water flow (2) l/h
394 749 822 432 846 925 1094 1190 1295 1225 1332 1448
Water pressure drop (2)(E) kPa
2 7 8 3 10 12 13 16 18 20 23 26
Heating capacity (3)(E) kW
3,40 5,17 5,45 3,40 5,17 5,45 6,42 6,73 7,06 6,42 6,73 7,06
FCCOP class (E)
A A C C
Water flow (3) l/h
297 452 477 297 452 477 562 589 618 562 589 618
Water pressure drop (3)(E) kPa
6 13 14 6 13 14 19 21 22 19 21 22
Standard coil - number of rows
38 55 58 38 55 58 61 63 69 61 63 69
Total sound power level (4) dB(A)
3+1 4+1 3+1 4+1
Inlet + radiated sound power level (4)(E) dB(A)
36 53 56 36 53 56 59 61 67 59 61 67
Outlet sound power level (4)(E) dB(A)
35 52 55 35 52 55 58 60 66 58 60 66
Water content - standard coil dm³
0,97 0,97 0,97 0,97
Cross-section area of power cables (5) mm²
1,00 1,00 1,50 1,50
Power supply cable type
N07V-K
Safety fuse F A
1 1 2 2
Fuses type
gG
(1) Water temperature 7°C / 12°C, air temperature dry bulb 27°C, wet bulb 19°C (47% relative humidity) according to EN1397:2015
(2) Water temperature 7°C / 12°C, air temperature dry bulb 27°C, wet bulb 19°C (47% relative humidity)
(3) Water temperature 65°C / 55°C, air temperature 20°C
(4) Sound power measured according to standards ISO 3741 and ISO 3742
(5) Sound pressure measured at a distance of 4 m in a free field with a directivity factor of 1
(E) EUROVENT certified data
Power supply 230-1-50 (V-ph-Hz)
