Daikin FWP CT - Overall Dimensions

FWPC
TECHNICAL MANUAL12
8 OVERALL DIMENSIONS
» FWP-C 04-05-06-08
LEGEND
1 Water connections standard heat exchanger 1/2" female
2 Water connections additional heat exchanger 1/2" female
3 Condensate discharge diameter ø 17
FWP-C 04 05 06 08
A mm 758 758 968 968
C mm 677 677 887 887
D mm 648 648 858 858
E mm 707 707 917 917
300
300
140
100
15
250
15
103 102
26
33
D
C
21 197
605
665
26
A
E
42
93
78
187
205
356
441
529
575
330
550
3
2
2
1
IN
IN
OUT
OUT
