FWPC
TECHNICAL MANUAL8
5 RATED TECHNICAL DATA
» 2 pipes
FWP-C 04 05 06 08
Speed
min med max min med max min med max min med max
Declared speed
2,5,7 1,5,7 1,6,7 1,4,7
Control voltage (E) V
2,90 8,00 9,00 4,30 7,50 8,40 4,50 7,40 8,30 5,40 8,30 9,90
Rated air flow (E) m³/h
109 246 276 171 275 341 195 360 402 305 532 652
Available static pressure (E) Pa
10 50 63 19 50 77 19 50 63 17 50 75
Power input (E) W
6 25 33 10 24 39 10 26 35 22 51 77
Maximum current absorption A
0,32 0,60 0,84 0,84
Total cooling capacity (1)(E) kW
0,93 1,76 1,95 1,29 1,95 2,34 1,59 2,74 3,04 1,98 3,26 3,79
Sensible cooling capacity (1)(E) kW
0,62 1,25 1,39 0,91 1,39 1,66 1,09 1,91 2,11 1,48 2,48 2,92
FCEER class (E)
A
Water flow (2) l/h
161 306 340 222 339 408 274 476 527 343 568 664
Water pressure drop (2)(E) kPa
2 5 6 3 6 8 3 7 9 3 8 11
Heating capacity (3)(E) kW
0,88 1,81 1,99 1,33 1,98 2,35 1,59 2,80 3,10 2,35 3,71 4,31
FCCOP class (E)
A
Water flow (3) l/h
153 315 346 231 345 408 276 488 538 408 644 749
Water pressure drop (3)(E) kPa
1 4 5 2 5 7 2 6 8 4 9 11
Standard coil - number of rows
3 3 4 3
Total sound power level (4) dB(A)
28 49 52 39 50 54 39 50 54 38 52 58
Inlet + radiated sound power level (4)(E) dB(A)
26 47 50 37 48 52 37 48 52 36 50 56
Outlet sound power level (4)(E) dB(A)
25 46 49 36 47 51 36 47 51 35 49 55
Water content - standard coil dm³
1,20 1,20 2,20 1,60
Cross-section area of power cables (5) mm²
1,00 1,00 1,00 1,00
Power supply cable type
N07V-K
Safety fuse F A
1 1 1 1
Fuses type
gG
FWP-C 10 11 15 17
Speed
min med max min med max min med max min med max
Declared speed
1,6,7 1,6,7 5,6,7 5,6,7
Control voltage (E) V
3,40 7,60 8,50 3,40 7,60 8,50 6,80 7,50 8,30 6,80 7,50 8,30
Rated air flow (E) m³/h
333 687 760 333 687 760 1050 1163 1289 1050 1163 1289
Available static pressure (E) Pa
12 50 61 12 50 61 40 50 60 40 50 60
Power input (E) W
11 54 68 11 54 68 105 128 162 105 128 162
Maximum current absorption A
0,91 0,91 3,52 3,52
Total cooling capacity (1)(E) kW
2,29 4,34 4,75 2,51 4,91 5,35 6,28 6,81 7,38 7,04 7,64 8,28
Sensible cooling capacity (1)(E) kW
1,67 3,21 3,51 1,77 3,45 3,76 4,64 5,03 5,46 4,96 5,38 5,84
FCEER class (E)
A A C B
Water flow (2) l/h
394 753 828 432 850 930 1094 1190 1295 1225 1332 1448
Water pressure drop (2)(E) kPa
2 7 8 3 10 12 13 16 18 20 23 26
Heating capacity (3)(E) kW
2,54 4,76 5,17 2,63 5,03 5,49 6,68 7,22 7,80 7,18 7,80 8,46
FCCOP class (E)
A A B B
Water flow (3) l/h
441 827 898 457 875 955 1162 1256 1356 1248 1355 1471
Water pressure drop (3)(E) kPa
2 7 8 3 9 11 12 14 16 17 19 22
Standard coil - number of rows
3 4 3 4
Total sound power level (4) dB(A)
38 55 58 38 55 58 61 63 69 61 63 69
Inlet + radiated sound power level (4)(E) dB(A)
36 53 56 36 53 56 59 61 67 59 61 67
Outlet sound power level (4)(E) dB(A)
35 52 55 35 52 55 58 60 66 58 60 66
Water content - standard coil dm³
2,50 3,30 2,50 3,30
Cross-section area of power cables (5) mm²
1,00 1,00 1,50 1,50
Power supply cable type
N07V-K
Safety fuse F A
1 1 2 2
Fuses type
gG
(1) Water temperature 7°C / 12°C, air temperature dry bulb 27°C, wet bulb 19°C (47% relative humidity) according to EN1397:2015
(2) Water temperature 7°C / 12°C, air temperature dry bulb 27°C, wet bulb 19°C (47% relative humidity)
(3) Water temperature 45°C / 40°C, air temperature 20°C
(4) Sound power measured according to standards ISO 3741 and ISO 3742
(5) Sound pressure measured at a distance of 4 m in a free field with a directivity factor of 1
(E) EUROVENT certified data
Power supply 230-1-50 (V-ph-Hz)
