Name and Operation of Each Part
Front
Air inlet for air quality
sensor (dust sensor)
Air inlet for
odour sensor
Receiver
Front panel
Model name / Serial number
Air inlet
Air outlet
Rear
Inside of the unit
Handles
Power supply cord hook
Can be used for winding the extra part of the
power supply cord.
► Page 12.
Remote controller storage slot
Stores the accessory remote
controller when not in use.
Remote
controller
Power plug
Power supply cord
Holds 4 replacement pleated
 lters.
► Page 9.
Filter container
Front panel
Ventilation fan
Ionised wire (rear)
Ionising frame
Opposing pole plates
Safety guard
Unit display
► Page 7, 8.
► Page 16.
► Page 16.
► Page 15.
(Streamer unit)
UNIT2
► Page 20.
(gray)
Deodorising catalyst unit
► Page 16.
(front: white, rear: blue)
Pleated  lter
► Page 21.
(Plasma ioniser)
UNIT1
► Page 19.
(green)
Pre lter
► Page 15.
Do not remove the safety guard.
(Electric shock or injury may occur.)
CAUTION
