www.DaikinApplied.com 25 IM 972-2 • MAVERICK I ROOFTOP SYSTEMS
Table 14: Auxiliary Heater Kits Characteristics and Application: 480V — 3 Phase
Unit Model Number
MPS
Heater Kit
Model No. RXJJ
Heater Kw @ 480V Heater Kit Fla Unit Min. Ckt. Ampacity
Max. Fuse or Ckt. Bkr. Size
(Ckt. Bkr. Must Be HACR
Type For USA)
015 Low Static Drive
NONE — — 38 45
CE20D 19.2 23.1 38 45
CE40D 38.4 46.2 64 70
CE60D 57.6 69.3 93 100
CE75D 72 86.6 114 125
015 High Static Drive
NONE — — 40 50
CE20D 19.2 23.1 40 50
CE40D 38.4 46.2 67 70
CE60D 57.6 69.3 95 100
CE75D 72 86.6 117 125
020 Low Static Drive
NONE — — 52 60
CE20D 19.2 23.1 52 60
CE40D 38.4 46.2 67 70
CE60D 57.6 69.3 95 100
CE75D 72 86.6 117 125
020 High Static Drive
NONE — — 56 70
CE20D 19.2 23.1 56 70
CE40D 38.4 46.2 70 70
CE60D 57.6 69.3 99 100
CE75D 72 86.6 121 125
025 Low Static Drive
NONE — — 60 70
CE20D 19.2 23.1 60 70
CE40D 38.4 46.2 70 70
CE60D 57.6 69.3 99 100
CE75D 72 86.6 121 125
025 High Static Drive
NONE — — 63 80
CE20D 19.2 23.1 63 80
CE40D 38.4 46.2 74 80
CE60D 57.6 69.3 103 110
CE75D 72 86.6 124 125
