Representative Unit Combination
Power Supply Comp OFM IFM
Indoor Unit Outdoor Unit Hz-Volts Voltage Range MCA MFA RHz RLA W FLA W FLA
FTXS50G2V1B RXS50G2V1B
50 - 220
Max. 50Hz 264V
Min. 50Hz 198V
19.75 20 70
6.6
53 0.27 23 0.15
50 - 230 6.2
SIMBOLS NOTES
MCA : Min. circuit amps. (A) 1 RLA is based on the following conditions.
Indoor temp. 27C°DB/19°CWB
Outdoor Temp. 35°CDB.
2 Maximum allowable voltage variation between phases is 2%.
3 Select wire size based on the lager value of MCA.
4 Instead of fuse, use circuit breaker.
MFA :
Max. Fuse Amps.
(A)
RLA : Rated Load Amps. (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Fan Motor Rated Output (W)
RHz : Rated Operated Frequency (Hz)
To Next Page
