Daikin R-410A Technical Data

• Split Sky Air • Outdoor Units
13
• Outdoor Units • R-410A • RXS-G2V1B
4 Capacity tables
4 - 1 Cooling/Heating capacity tables
3
4
FTXS20G2V1B + RXS20G2V1B
Cooling 50Hz 220-240V
Heating 50Hz 220-240V
3D059714
Indoor Outdoor temperature (°C DB)
EWB EDB 20 25 30 32 35 40
°C°CTCSHCPI TCSHCPI TCSHCPI TCSHCPI TCSHCPI TCSHCPI
14.0 20 2.05 1.84 0.36 1.96 1.80 0.40 1.86 1.76 0.43 1.83 1.74 0.44 1.77 1.71 0.46 1.68 1.67 0.50
16.0 22 2.14 1.81 0.36 2.05 1.77 0.40 1.95 1.73 0.43 1.92 1.72 0.45 1.86 1.69 0.47 1.77 1.66 0.50
18.0 25 2.23 1.94 0.36 2.14 1.90 0.40 2.05 1.87 0.43 2.01 1.85 0.45 1.95 1.83 0.47 1.86 1.80 0.50
19.0 27 2.28 2.09 0.37 2.19 2.05 0.40 2.09 0.40 2.09 2.02 0.44 2.06 2.00 1.98 0.47 1.91 1.95 0.50
22.0 30 2.42 2.03 0.37 2.32 2.00 0.40 2.23 1.97 0.44 2.19 1.96 0.45 2.14 1.94 0.47 2.05 1.91 0.51
24.0 0.51 2.51 1.99 0.37 2.42 1.96 0.41 2.32 1.93 0.44 2.29 1.92 0.45 2.23 1.91 0.48 2.14 1.88 0.51
Indoor Outdoor temperature (°C DB)
EDB -10 -5 0 6 10
°C TC PI TC PI TC PI TC PI TC PI
15.0 1.82 0.53 2.12 0.56 2.43 0.58 2.79 0.62 3.04 0.64
20.0 1.72 0.55 2.03 0.57 2.33 0.60 2.70 0.63 2.94 0.65
22.0 1.69 0.55 1.99 0.58 2.30 0..60 2.66 0.64 2.91 0.66
24.0 1.65 0.56 1.95 0.58 2.26 0.61 2.63 0.64 2.87 0.66
25.0 1.63 0.56 1.94 0.59 2.24 0.61 2.61 0.64 2.85 0.66
27.0 1.59 0.57 1.90 0.59 2.20 0.62 2.57 0.65 2.81 0.67
SYMBOLS NOTES
AFR : Air flow rate (m3/mim.) 1 Ratings shown are net capacities which include a deduction for indoor
fan motor heat.
2 shows nominal (rated) capacities and power input.
3 TC, PI and SHC must be calculated by interpolation using the figures
in the above tables. (Figures out of the tables should be used for
calculation.)
4 About SHC which are not mentioned on the table.
please calculate them with around values in direct proportion.
5 Capacities are based on the following conditions.
Corresponding refrigerant piping lenght : 5m
Level difference : 0m
6 Air flow rate (AFR) and Bypass factor (BF) are tabulated above table.
BF : Bypass factor
EWB : Entering wet bulb temp. (°C)
EDB : Entering dry bulb temp. (°C)
TC : Total capacity (kW)
SHC : Sensible heat capacity (kW)
PI : Power input (kW)
AFR 9.4
BF 0.14
AFR 9.9
