Daikin R-410A Technical Data

• Outdoor Units • R-410A • RXS-G2V1B
• Split Sky Air • Outdoor Units
8
3 Electrical data
3
24
3
3D055006B
Representative Unit Combination Power Supply Comp OFM IFM
Indoor Unit Outdoor Unit Hz-Volts Voltage Range MCA MFA RHz RLA W FLA W FLA
FTXS20G2V1B RXS20G2V1B 50 - 220
Max. 50Hz 264V
Min. 50Hz 198V
9.75 10 34
2.3
50 0.23 23 0.15
2.2
SIMBOLS NOTES
MCA : Min. circuit amps. (A) 1 RLA is based on the following conditions.
Indoor temp. 27C°DB/19°CWB
Outdoor Temp. 35°CDB.
2 Maximum allowable voltage variation between phases is 2%.
3 Select wire size based on the lager value of MCA.
4 Instead of fuse, use circuit breaker.
MFA :
Max. Fuse Amps. (A)
RLA : Rated Load Amps. (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Fan Motor Rated Output (W)
RHz : Rated Operated Frequency (Hz)
3D055008B
Representative Unit Combination Power Supply Comp OFM IFM
Indoor Unit Outdoor Unit Hz-Volts Voltage Range MCA MFA RHz RLA W FLA W FLA
FTXS25G2V1B RXS25G2V1B 50 - 230
Max. 50Hz 264V
Min. 50Hz 198V
9.75 10 34
2.7
50 0.23 23 0.15
2.5
SIMBOLS NOTES
MCA : Min. circuit amps. (A) 1 RLA is based on the following conditions.
Indoor temp. 27C°DB/19°CWB
Outdoor Temp. 35°CDB.
2 Maximum allowable voltage variation between phases is 2%.
3 Select wire size based on the lager value of MCA.
4 Instead of fuse, use circuit breaker.
MFA :
Max. Fuse Amps. (A)
RLA : Rated Load Amps. (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Fan Motor Rated Output (W)
RHz : Rated Operated Frequency (Hz)
