Daikin R-410A Technical Data

• Split Sky Air • Outdoor Units
9
• Outdoor Units • R-410A • RXS-G2V1B
3 Electrical data
3
3
Representative unit combination Power supply Comp. OFM IFM
Indoor unit Outdoor unit Hz-volts Voltage range MCA MFA RHz RLA W FLA W FLA
FFQ25B8V1B RXS25G2V1B
50 - 220
50 - 230
50 - 240
Max. 50Hz 264V
Min. 50Hz 198V
9.75 10 55
3.7
23 0.16 55 0.63.5
3.4
3D055010B
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency (Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Rated motor output (W)
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
http://extranet.daikineurope.com, select ’’E-Data Books’’. Finally, click on
the document title of your choice.
3D055009B
Representative Unit Combination Power Supply Comp OFM IFM
Indoor Unit Outdoor Unit Hz-Volts Voltage Range MCA MFA RHz RLA W FLA W FLA
FTXS35G2V1B RXS35G2V1B 50 - 230
Max. 50Hz 264V
Min. 50Hz 198V
9.75 10 65
3.9
50 0.23 23 0.15
3.7
SIMBOLS NOTES
MCA : Min. circuit amps. (A) 1 RLA is based on the following conditions.
Indoor temp. 27C°DB/19°CWB
Outdoor Temp. 35°CDB.
2 Maximum allowable voltage variation between phases is 2%.
3 Select wire size based on the lager value of MCA.
4 Instead of fuse, use circuit breaker.
MFA :
Max. Fuse Amps. (A)
RLA : Rated Load Amps. (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Fan Motor Rated Output (W)
RHz : Rated Operated Frequency (Hz)
