Representative unit combination Power supply Comp. OFM IFM
Indoor unit Outdoor unit Hz-volts Voltage range MCA MFA RHz RLA W FLA W FLA
FFQ35B8V1B RXS35G2V2B
50 - 220
50 - 230
50 - 240
Max. 50Hz 264V
Min. 50Hz 198V
9.75 10 79
4.8
23 0.16 55 0.64.6
4.4
3D055011B
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency (Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Rated motor output (W)
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
http://extranet.daikineurope.com, select ’’E-Data Books’’. Finally, click on
the document title of your choice.
SYMBOLS
MCA: Min. Circuit Amps. (A)
MFA: Max. Fuse Amps (A) (see note 4). (A)
RHZ: Rated Operating Frequency (Hz)
RLA: Rated Load Amps. (A)
OFM: Outdoor Fan Motor (A)
IFM: Indoor Fan Motor
FLA: Full Load Amps. (A)
w: Fan Motor Rated Outdput (W.)
Units Power supply Compressor OFM IFM
Indoor units Outdoor units Hz
Voltage range
MCA MFA RHz RLA W FLA W FLA
FBQ35C7VEB RXS35G2V1B
50 - 230
Max. 50Hz 253V
Min. 50Hz 207V
15 16 70 4.42 19 0.35 140 1.2
FBQ50C7VEB RXS50G2V1B 18 20 75 7 53 0.18 140 1.2
NOTES
1 RLA is based on the following conditions.
Indoor temp. 27°CDB / 19.0°CWB
Outdoor temp. 35°C
2 Maximum allowable woltage variation between fases is 2%
3 Select wire size based on the value of MCA
4 MFA is used to select the circuit break earth leakage circuit breaker.
5 Voltage range.
Units are suitable for use on electrical systems where voltage
supplied to unit terminals is not below or above listed range limits.
6 MCA represents maximum input current.
MFA represents capacity which may accept MCA
(next lower standard fuse rating minimum 15A)
3TW25081-2F
