Daikin R-410A Technical Data

• Split Sky Air • Outdoor Units
7
• Outdoor Units • R-410A • RXS-G2V1B
2 Specifications
3
2
Sound Level
(nominal)
Cooling Sound Power dBA 61 61 63 63 62
Sound Pressure
(Low)
dBA4343444444
Sound Pressure
(High)
dBA4646484848
Heating Sound Pressure
(Low)
dBA4444454545
Sound Pressure
(High)
dBA4747484848
Refrigerant Type R-410A
Charge kg 0.8 1.0 1.2 1.3 1.7
Refrigerant Oil Type FVC50K
Charged Volume l 0.375 0.375 0.375 0.65 0.65
Piping connections Liquid (OD) Diameter (OD) mm 6.35 6.35 6.35 6.35 6.35
Gas Diameter (OD) mm 9.52 9.52 9.52 9.52 12.7
Drain Diameter (OD) mm 18 18 18 18 18
Piping Length Maximum m 20 20 20 20 30
Additional Refrigerant Charge kg/m 0.02>10m
Installation height
difference
Maximum m 15 15 15 15 20
Heat Insulation Both liquid and gas pipes
Standard
Accessories
Item Installation manual
Quantity 11111
Item Drain plug
Quantity 1
Notes Nominal cooling capacities are based on: indoor temperature: 27°CDB, 19.0°CWB; outdoor
temperature: 35°CDB, 24°CWB, refr.pip.length: 5m
Nominal heating capacities are based on: indoor temperature: 20°CDB; outdoor temperature: 7°CDB,
6°CWB, refr.pip.length: 5m
2-3 ELECTRICAL SPECIFICATIONS RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B
Power Supply Name V1
Phase 1~
Frequency Hz 50 50 50 50 50
Voltage V 220-230-240
Current Nominal running
current (RLA)
Cooling (A) A 2.67-2.55-2.45 3.06-2.93-2.81 4.26-4.08-3.91 6.04-5.78-5.54 6.93-6.63-6.35
Heating (A) A 3.50-3.35-3.21 4.14-3.96-3.80 4.71-4.50-4.31 7.27-6.96-6.67 7.13-6.82-6.54
Starting current (cooling/heating) A 3.6 4.3 4.8 7.4 7.3
Wiring connections For Power Supply Quantity 3 3 3 3 3
For connection with
indoor
Quantity 4 4 4 4 4
Remark (including earth wiring)
2-2 TECHNICAL SPECIFICATIONS RXS20G2V1B RXS25G2V1B RXS35G2V1B RXS42G2V1B RXS50G2V1B
