IM 893-10 • ROOFPAK SINGLEZONE UNITS 118 www.DaikinApplied.com
keyPad/dIsPlay Menu sTruCTure
Figure 118 continued: Commission Unit – Keypad/Display Menu Structure
Econo Set-Up
EconChgovr= Enth&DB
Econo FDD= On
Clg Stage Time= 5min
Chgover Temp= 55.0°F
Clg DB= 2.0°F
Econo Period=
30/40s (air/water)
Econo Gain=
1-Oct (air/water)
Econo PAT=
60/40s (air/water)
Econo Max Chg=
10/15% (air/water)
Flush Econo= Yes
Econo Diff= 2.0°F
EWT Diff= 3.0°F
Clg Reset= None
Min Clg Spt= 55.0°F
Min Clg Spt @= 0/NA
Max Clg Spt= 65.0°F
Max Clg Spt@= 100/NA
Max OAT Lmt= 75°F
Min OAT Lmt= 70°F
Calibrate OAD= No
PosSwOpen= 97%
Max Sw Diff= 3%
PosSwClose= 3%
Min SW Diff= 5%
OAD Sw Status= _______
Timer Settings
Service Time= 0min
Start Up= 180s
Recirculate= 180s
Zero OA Time= 0min
Tnt Override= 120min
Post Heat= 0s
Pwd Timeout= 10min
Low DAT= 6min
ClgStateDelay= 300s
Bypass Valve= 300s
Clg Stg Time= 5min
Htg Stg Time= 5min
Air Flw Ign= 120s
MinExStrtTm= 120s
MinExStopTm= 120s
ER Whl Stg Tm= 5min
ER Whl Off Tm= 20min
EvCnd Stg Tm= 10min
WRV Init Tm= 60s
Min WRV Time= 60s
Htg Wrmup Tm= 240s
Htg Hld Period= 240s
RH Srg Time= 10min
Srvc Time Inc= 20s
OffHtCIDelay= 120s
Unit Set-Up
Apply Changes= No
RAT Sensor= Yes
OAT Sensor= Yes
Space Sensor= Digtl/Net
Eng Units= English
Unit Name= xxxxxxxxxxxx
Rapid Start= No
Rapid Start Tm= 10min
DO10 Clg= FanOp
SAF Set-Up
SAF Ctrl= DSP CO
2
CONTROL BSP CONTROL
AplyInputChgs= No Min PPM= 0PPM BSP DB= 0.01in
CO2 Input= None Max PPM= 2000PPM BSP Period= 5s
CFM Input= None V/A @ Min PPM= 0V BSP Gain= 0.2
BSP Input= No V/A @ Max PPM= 10V Max Spd Chg= 4%
SPEED CONTROL Min SAF PPM= 800PPM SAF SETUP
Rem SAF Cap= 33% Max SAF PPM= 1100PPM SAF Ctrl Dly= 30s
DSP CONTROL Min PPM Spd= 50% Min Speed= 33%
DSP DB= 0.1in Max PPM Spd= 100% VAVBox Out= _________
VFD Ramp Time= 60s CFM CONTROL Max SAF Hz=
Min Period= 5s Min CFM= 0CFM Max Vent Speed= 100%
Max Spd Chg= 15% Max CFM= 10000CFM Max SAF RPM= 2600
Duct Press 1= X.Xin V/A @ Min CFM= 0V ECM Status= __________
Duct Press 2= X.Xin V/A @ Max CFM= 10 V
1 ZONE VAV CONTROL SAF CFM DB= 3%
Min Clg Spd= 40% SAF CFM Period= 30s
Max Clg Spd= 100% SAF CFM Gain= 0.1
Min Htg Spd= 40% SAF CFM MxChg= 5%
Max Htg Spd= 100%
Space Period= 60s
Space Gain= 0.8
Space PAT= 400s
Space Max Chg= 10%
Compressor Limiting
Clg Press Lmtg=_______
Htg Press Lmtg=_______
C Ratio Lmtg=_________
Ref DLT Lmtg=_________
INV Brd Lmtg=_________
INV Man Dsbl= Enable
Comp3 ManDsbl= Enable
Date/Time
MM/DD/YYYY HH:MM:SS
INV Cmp Set-Up
COMPRESSOR STATUS COMPRESSOR SETUP
Clg State= ____________
Clg Lo OAT Lk=
55°F (RTU/SCU)
0°F (MPS)
25°F (DPS)
Htg State= ____________
INV Cmp Spd= XXX.X%
INV Spd Cmd= XXX.X%
Comp 3=_____________
Htg Lo OAT Lk=
0.0ºF
45°F (100% OA w/o ER)
Prev Standby=_______
►
Compressor Limiting
►
Fault Code Details
►
Htg Hi OAT Lk= 55.0ºF
INV Port Temp= XXX.XºF EffHtgOATLk= _______ºF
INV Fin Temp= XXX.XºF OAT Diff= 2ºF
INV Cmp Amps= XX.XA INV Period= 20s
REFRIG CIRCUIT STATUS INV Gain= 2.5
PTD= XXX.Xpsi INV PAT= 10s
PTS= XXX.Xpsi INV Max Chg= 15%
4 Way Valve=__________
IFB COMM STATUS
►
RcvrSol Valve=_________
BP Sol Valve=_________
1
2
Commission Unit
Unit Set-Up
►
Timer Settings
►
SAF Set-Up
►
RF/EF Set-Up
►
Htg/Clg ChgOvr Set-Up
►
Cooling Set-Up
►
INV Cmp Set-Up
►
Var Cmp Set-Up
►
Econo Set-Up
►
Min OA Set-Up
►
Heating Set-Up
►
OA Fan Set-Up
►
Exp Valve Set-Up
►
Defrost Set-Up
►
Dehum Set-Up
►
Energy Rec Set-Up
►
Head Pressure Set-Up
►
Evap Cond Set-Up
►
D3 Set-Up
►
Alarm Conguration
►
Var Comp Set-Up
COMPRESSOR STATUS
Var Cmp Status= _______
Var Spd Cmd= _________
Comp 1= _____________
Comp 3= _____________
Comp 5= _____________
REFRIG CIRCUIT STATUS
PTD1= _______________
PTD2= _______________
VCmpDischSH= _______
C1DschSatTmp= _______
C2DschSatTmp= _______
DRT1= _______________
DRT2= _______________
Cond Sol 1= Off
Cond Sol 2= Off
COMPRESSOR SET-UP
Var Cmp Period= 20s
Var Cmp Gain= 1
Var Cmp PAT= 40s
VarCmp MaxChg= 10%
OilBoost= Off
LowOilTime= 10min
OilBoostTime= 15min
LowTcOAT= 80°F
1, 2 See the expansion
information on page 125
List continues
on, page 120
