keyPad/dIsPlay Menu sTruCTure
www.DaikinApplied.com 121 IM 893-10 • ROOFPAK SINGLEZONE UNITS
Dehum Set-Up
Dehum Method= None
RH DB= 2%
Dewpoint DB= 2°F
RH Period= 30s
RH Gain= 1
RH PAT= 30s
RH Max Chg= 10%
RH Stg Time= 10min
Stg Rht DB= 5.0°F
Dehum Ctrl= Occupied
Sensor Loc= Return
Mn Lvg Coil T= 45.0°F
Mx Lvg Coil T= 52.0°F
Rht Cmp Lmtg= Yes
Min Rheat Spt= 55.0°F
Max Rheat Spt= 65.0°F
RH Sens Type= VDC
RH Min Sig= 0.0V
RH Max Sig= 10.0V
Min Dehum Spd= 33%
Max Dehum Spd= 100%
Rht Min Pos= 10% (RPS)
15% (MPS)
5% (DPS, DPH)
RH Dec Rate= 1
RHOutMaxV= 10
Energy Rec Set-Up
Energy Rcvy= Yes
ER Wheel= ___________
Wheel Speed= XXX%
Whl Spd Cmd= XXX%
ER LAT= XXX°F
ER EAT= XXX°F
Min ExhT Diff= 2.0°F
Max ExhT Diff= 6.0°F
ER Whl Stg Tm= 5min
ER Whl Off Tm= 20min
Rel Humidity= XXX%
Min Whl Spd= 5%
Intersect Pt= XXX.XºF
Fst Mgnt Meth= Timed
OA Frst Temp= -20.56°F
Defrost Time= 5min
Defrost Period= 60min
Defrst On Tm= 1s
Defrst Off Tm= 24s
ER Whl Period= 30s
ER Whl Gain= 1.0
ER Whl PAT= 30s
ER Max Chg= 10%
LoERLATCmpLk= 45.0°F
Head Pressure Set-Up
Wtr Reg Vlv= XXX%
Head P Circ 1= XXXPSI
Head P Circ 2= XXXPSI
Setpoint= 260PSI
Head Press DB= 10PSI
WRV Period= 10s
WRV Gain= 3.6
WRV PAT= 10s
WRV Max Chg=7%
WRV Init Tm= 60s
Min WRV Pos=10%
Min WRV Tmp= 58°F
Max WRV Tmp= 150°F
WRV Act Time= 60s
Min WRV Time= 60s
Defrost Set-Up
Defrost State= _________
Manual DF= No
MinCmpOpTm= 10min
MinAccCmpTm= 40min
MaxFrostTm= 120min
Defrost Temp= XXºF
Tdef Adj= 0.0ºF
CmpOpTm= XXXmin
AccCmpOpTm= XXXmin
LoFrstAccTm= XXXmin
HiFrstAccTm= XXXmin
