Daikin RDT Installation And Maintenance Manual

InTroduCTIon
www.DaikinApplied.com 17 IM 893-10 • ROOFPAK SINGLEZONE UNITS
Table 4: R-410A Fan Cycling Setpoints in °F with No Controls
RPS, RCS, RDT, RPR Control ID
Degrees °F Notes
Cut Out Cut In Differential
015 TC12 65 70 5 TC12 Controls 1 Fan
016 TC12 70 75 5 TC12 Controls 1 Fan
020 TC12 65 70 5 TC12 Controls 1 Fan
021 TC12 70 75 5 TC12 Controls 1 Fan
025 TC12 55 60 5 TC12 Controls 1 Fan
026 TC12 65 70 5 TC12 Controls 1 Fan
030 TC12 70 75 5 TC12 Controls 1 Fan
031 TC12 70 75 5 TC12 Controls 1 Fan
035 TC12 65 70 5 TC12 Controls 1 Fan
040 TC12 60 65 5 TC12 Controls 1 Fan
042 TC12 60 65 5 TC12 Controls 1 Fan
045 TC12 60 65 5 TC12 Controls 1 Fan
050 TC12 60 65 5 TC12 Controls 1 Fan
051 TC12 65 70 5 TC12 Controls 1 Fan
061 TC12 55 60 5 TC12 Controls 1 Fan
063 TC12 65 70 5 TC12 Controls 1 Fan
068 TC12 65 70 5 TC12 Controls 1 Fan
070
TC12 65 70 5 TC12 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
071
TC12 65 70 5 TC12 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
075
TC12 60 65 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
079
TC12 65 65 5 TC12 Controls 1 Fan
TC14 75 80 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
080
TC12 70 75 5 TC12 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
081
TC12 70 75 5 TC12 Controls 1 Fan
PC13/PC23 90 12 35 PC13/PC23 Controls 1 Fan*
085
TC12 65 70 5 TC12 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
090
TC12 55 60 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
091
TC12 55 60 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
100
TC12 55 60 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
101
TC12 55 60 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 3 PC13/PC23 Controls 1 Fan*
105
TC12 45 50 5 TC12 Controls 1 Fan
TC14 75 80 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
110
TC12 60 65 5 TC12 Controls 1 Fan
TC14 85 90 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
120
TC12 60 65 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fans
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
125
TC12 60 65 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
130
TC12 55 60 5 TC12 Controls 1 Fan
TC14 80 85 5 TC14 Controls 1 Fan
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
140
TC12 50 55 5 TC12 Controls 1 Fan
TC14 75 80 5 TC14 Controls 2 Fans
PC13/PC23 90 125 35 PC13/PC23 Controls 1 Fan*
* PC13/23Cut in = 450 psig (125 degree sat.), Fixedcut out = 275 psig (90 degree sat.), Fixed
