Outdoor Unit Si18-797
20 Removal Procedure
1.3 Removal of Solenoid Valve, Four Way Valve and
Motorized Valve
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1. Remove the solenoid
valve coil, motorized valve
coil and four way valve
coil.
1
Remove the solenoid
valve and four way
valve.
Remove the screw.
Use two open end wrenches for
disassembling.
2
Remove the motorized
valve.
Solenoid valve
(Q0491)
Motorized
valve.
Four way
valve
Solenoid
valve
(Q0492)
(Q0493)
