BP Unit Si18-797
26 Removal Procedure
3
Disconnect the solenoid
valve connector and the
thermistor connector.
4
Remove the screw off
the wire harness band.
5
Remove the screw off
the grounding lug.
Step
Procedure Points
(Q0504)
(Q0505)
(Q0506)
