Si18-797 Outdoor Unit
Removal Procedure 3
2. Remove the rear
protective net.
1
Undo the 3 top hooks
first.
Bend the rear protective net
slightly for easy removal.
2
Next, undo the 4 right-
side hooks. (See the
figure at bottom.)
3
Remove the rear
protective net.
Step
Procedure Points
Hooks
(Q0448)
(Q0449)
(Q0450)
Hooks
