All dimensions are in mm
Dimension
Model
A B C D E F G H I J K L M
FT20/25LV1L
FT20/25LV1M
FTN20/25PV1L
FTN20/25PV1M
FT20/25MV1I
FT20/25MV1J
FTN20/25MV1I9
FTN20/25MV1J9
1065 310 190 173 61 40 45 48 91 219 580 45
1065 310 233 190 173 61 40 45 48 91 219 580 45
stopsnoitneteretalpgnitnuomdednemmoceR
(7 spots in all)
D
B
G
H J
L
M
A
K
F
I
G F
E
Through the wall hole Ø 65mm
Drain hose position
Liquid pipe end Gas pipe end
INSTALLATION PLATE: FT20/25LV1L, FT20/25LV1M & FT20/25MV1I, FT20/25MV1J
FTN20/25PV1L, FTN20/25PV1M & FTN20/25MV1I9, FTN20/25MV1J9
Indoor Unit
Model : FT311V1L, FT311V1M
FTN311V1L, FTN311V1M
Note : Dimension in mm
200.0
360.0
327.0
347.0
224
228
