46
TM-FT-0415-B
All dimensions are in mm
Outdoor Unit
Model: R18/20/25/31CV1
RN20/25/28CV1
Dimension
Model
A
855 628 328 520 179 46 93 149 101 113 603 126 164 17 34
855 730 328 533 182 44 93 149 101 113 603 126 164 17 47
B C D E F G H I J K L M N O
R18/20CV1
RN20/25CV1
R18/20CV1
RN20/25CV1
R25/31CV1
RN28CV1
R25/31CV1
RN28CV1
Dimension
Model
P Q R S T
32 23 73 75
32 23 73 75
3
3
A
N
B
LL
M
C
O
D
N
C
HG
FE
JI
P
Q
TS
R
K
