Daikin RZAG71N V1B Series Installation Manual

Installation
Installation manual
11
RZAG71~140N7V1+Y1
Sky Air Alpha-series
4P573382-1 – 2019.04
To determine the additional refrigerant amount (R in kg) (in
case of pair)
Standard piping size
L1 (m)
L1: 40~50m 50~55m 55~60m 60~70m 70~80m 80~85m
R: 0.35kg 0.7kg
(a)
0.55kg
(b)
0.7kg
(a)
1.05kg
(a)
1.4kg
(a)
1.55kg
(a)
(a) Only for RZAG100~140.
(b) Only for RZAG71.
Size-up piping size
L1 (m)
L1: 15~20m 20~25m 25~30m 30~35m
R: 0.35kg 0.7kg 1.05kg
(a)
1.4kg
(a)
(a) Only for RZAG100~140.
To determine the additional refrigerant amount (R in kg) (in
case of twin, triple and double twin)
1 Determine G1 and G2.
G1 (m) Total length of <x> liquid piping
x=Ø9.5mm (standard)
x=Ø12.7mm (size‑up)
G2 (m) Total length of Ø6.4mm liquid piping
2 Determine R1 and R2.
If Then
G1>40m
(a)
Use the table below to determine
R1 (length=G1−40m)
(a)
and R2
(length=G2).
G1≤40m
(a)
(and G1+G2>40m)
(a)
R1=0.0kg.
Use the table below to determine
R2 (length=G1+G2−40m)
(a)
.
(a) In case of size‑up: Replace 40m by 15m.
In case of standard liquid pipe size:
Length
0~10m 10~15m 15~20m 20~30m 30~40m 40~45m
R1: 0.35kg 0.7kg
(a)
0.55kg
(b)
0.7kg
(a)
1.05kg
(a)
1.4kg
(a)
1.55kg
(a)
R2: 0.2kg 0.4kg 0.4kg 0.6kg 0.8kg
(a)
1kg
(a)
(a) Only for RZAG100~140.
(b) Only for RZAG71.
In case of size‑up liquid pipe size:
Length
0~5
m
5~10
m
10~15
m
15~20
m
20~30
m
30~40
m
40~45
m
R1: 0.35kg 0.7kg 1.05kg
(a)
1.4kg
(a)
— — —
R2: 0.35kg 0.7kg
(a)
1.05kg
(a)
1.4kg
(a)
—
(a) Only for RZAG100~140.
3 Determine the additional refrigerant amount: R=R1+R2.
Examples
Layout Additional refrigerant amount (R)
L2=7 m
(Ø6.4 mm)
L3=5 m
(Ø6.4 mm)
L1=45 m (Ø9.5 mm)
RZAG100
Case: Twin, standard liquid pipe size
1 G1 Total Ø9.5 => G1=45m
G2 Total Ø6.4 => G2=7+5=12m
2 Case: G1>40m
R1 Length=G1−40m=5m
=> R1=0.35kg
R2 Length=G2=12m
=> R2=0.4kg
3 R R=R1+R2=0.35+0.4=0.75kg
L2=20 m
(Ø6.4 mm)
L3=17 m
(Ø6.4 mm)
L4=17 m
(Ø6.4 mm)
L1=15 m (Ø9.5 mm)
RZAG125
Case: Triple, standard liquid pipe size
1 G1 Total Ø9.5 => G1=15m
G2 Total Ø6.4 => G2=20+17+17=54m
2 Case: G1≤40m (and G1+G2>40m)
R1 R1=0.0kg
R2 Length=G1+G2−40m=15+54−40=2
9m
=> R2=0.6kg
3 R R=R1+R2=0.0+0.6=0.6kg
Charging refrigerant: Setup
See "4.3.1Checking refrigerant piping: Setup"on page8.
To charge additional refrigerant
WARNING
▪ Only use R32 as refrigerant. Other substances may
cause explosions and accidents.
▪ R32 contains fluorinated greenhouse gases. Its global
warming potential (GWP) value is 675. Do NOT vent
these gases into the atmosphere.
▪ When charging refrigerant, ALWAYS use protective
gloves and safety glasses.
Prerequisite: Before charging refrigerant, make sure the refrigerant
piping is connected and checked (leak test and vacuum drying).
1 Connect the refrigerant cylinder to both the service port of the
gas stop valve and the service port of the liquid stop valve.
2 Charge the additional refrigerant amount.
3 Open the stop valves.
4.4.6 Completely recharging refrigerant
To determine the complete recharge amount
To determine the complete recharge amount (kg) (in case of
standard liquid pipe size)
Model Length (m)
(a)
3~40 40~50 50~55 55~60 60~70 70~80 80~85
RZAG71 3.2 3.55 3.75 — — — —
RZAG100 3.2 3.55 3.9 4.25 4.6 4.75
RZAG125-140 3.7 4.05 4.4 4.75 5.1 5.25
(a) Length=L1 (pair); L1+L2 (twin, triple); L1+L2+L4 (double
twin)
To determine the complete recharge amount (kg) (in case of
size‑up liquid pipe size)
Model Length (m)
(a)
3~15 15~20 20~25 25~30 30~35
RZAG71 3.2 3.55 3.9 — —
