SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series SiBE18-821_C
258 Operation Manual
BRC1D528
Remote controller
4PW23717-1
Operation manual
6
2 DRY OPERATION
3 AUTOMATIC OPERATION
4 COOLING OPERATION
5 HEATING OPERATION
6 LIMIT OPERATION
Fan only operation
Dry operation
Automatic operation
Cooling operation
Heating operation
Use the button to select the desired operation
mode.
Press the button to toggle between limit
operation and the operations listed above.
In limit operation, use the button to select
minimum and maximum temperature settings. Use
the or buttons to adjust the
minimum and maximum temperature settings.
1
FAN ONLY OPERATION
User adjustable parameters:
• Fan speed, use the button,
• Air flow direction adjust, use the button,
• Ventilation mode, use the button,
• Ventilation amount, use the button.
User adjustable parameters:
• Air flow direction adjust, use the button,
• Ventilation mode, use the button,
• Ventilation amount, use the button.
User adjustable parameters:
• Setpoint temperature, use the &
buttons,
• Fan speed, use the button,
• Air flow direction adjust, use the button,
• Ventilation mode, use the button,
• Ventilation amount, use the button.
User adjustable parameters:
• Fan speed, use the button,
• Air flow direction adjust, use the button,
• Ventilation mode, use the button,
• Ventilation amount, use the button.
User adjustable parameters:
• Setpoint temperature, use the &
buttons,
• Fan speed, use the button,
• Air flow direction adjust, use the button,
• Ventilation mode, use the button,
• Ventilation amount, use the button.
User adjustable parameters:
• Setpoint temperature, use the &
buttons,
• Fan speed, use the button,
• Air flow direction adjust, use the button,
• Ventilation mode, use the button,
• Ventilation amount, use the button.
