SiBE18-821_C SA Indoor Unit - FFQ, FCQ, FDBQ, FBQ, FHQ Series
Operation Manual 267
English 9
1. Operation mode selector button
2. Fan speed control button
3. Menu/Enter button
•
8. On/Off button
9. Operation lamp (Green)
10. Cancel button
11. LCD (with backlight)
4. Up button (Be sure to press the
part with the symbol )
5. Down button (Be sure to press
the part with the symbol )
6. Right button (Be sure to press
the part with the symbol )
• Used to highlight the next items on the
right-hand side.
• Each screen is scrolled in the right-hand
direction.
• Home leave settings are enabled with this
button kept pressed for at least four
seconds. (See page 19.)
• Used to lower the set temperature.
• The next items on the lower side will be
highlighted.
• (The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
• The backlight will be light for
approximately 30 seconds by pressing
any operation button. Operate buttons
excluding the On/ Off button while the
backlight is lit.
• If two remote controllers are used to
control a single indoor unit, the backlight
of the remote controller operated earlier
than the other one will be lit.
• This lamp lights up during operation.
• This lamp blinks if a error occurs.
• Press this button and system will start.
• Press this button again and system will
stop.
• Used to return to the previous screen.
• Used to raise the set temperature.
• The next items on the upper side will be
highlighted.
• (The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
• Used to indicate the main menu.
(See page 24 for the menu items.)
• Used to enter the setting item selected.
• Press this button to select the fan speed of
your preference. (See page 15.)
*Available fan speed vary with the
connecting model.
• Press this button to select the operation
mode of your preference. (See page 14.)
*Available modes vary with the connecting
model.
7. Left button (Be sure to press
the part with the symbol )
• Used to highlight the next items on the
left-hand side.
• Each screen is scrolled in the left-hand
direction.
• Home leave settings are enabled with this
button kept pressed for at least four
seconds. (See page 19.)
To Next Page
