Specifications SiBE18-821_C
16 Specifications
50 Hz, 220 - 230 - 240 V
Model
FTXS20G2V1B FTXS25G2V1B
Cooling Heating Cooling Heating
Rated Capacity 2.0 kW Class 2.5 kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 9.4 (332) 9.9 (350) 9.1 (321) 9.8 (346)
M 7.4 (262) 8.2 (290) 7.1 (252) 7.9 (280)
L 5.5 (193) 6.5 (228) 5.2 (182) 6.2 (217)
SL 4.0 (141) 5.5 (193) 3.7 (130) 5.2 (183)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21 18 - 18 - 18 21 - 21 - 21
Power Factor (Rated) % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 9 9
Gross Weight (Gross Mass) kg 13 13
Operation
Sound
H / M / L / SL dBA 38 / 32 / 25 / 22 38 / 33 / 28 / 25 38 / 32 / 25 / 22 39 / 34 / 28 / 25
Sound Power dBA 54 54 54 55
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D059722 3D059723
Model
FTXS35G2V1B FTXS42G2V1B
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 4.2 kW Class
Front Panel Color White White
Airflow Rates
m³/min
(cfm)
H 10.4 (367) 10.6 (374) 9.1 (321) 11.2 (395)
M 7.7 (270) 8.5 (302) 7.7 (273) 9.4 (333)
L 4.8 (170) 6.4 (226) 6.3 (221) 7.7 (271)
SL 3.5 (125) 5.4 (191) 5.4 (190) 6.8 (240)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12 0.11 - 0.11 - 0.10 0.14 - 0.14 - 0.13
Power Consumption (Rated) W 26 - 26 - 26 28 - 28 - 28 24 - 24 - 24 30 - 30 - 30
Power Factor (Rated) % 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2 99.2 - 94.9 - 100.0 97.4 - 93.2 - 96.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 13 13
Operation
Sound
H / M / L / SL dBA 42 / 34 / 26 / 23 42 / 36 / 29 / 26 42 / 38 / 33 / 30 42 / 38 / 33 / 30
Sound Power dBA 58 58 58 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D059724 3D059725
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
