Outdoor Unit SiBE18-821_C
452 Removal Procedure
4
Remove the sound
insulation for the
compressor.
5
Remove the crankcase
heater at the lower of
the compressor.

Pull the spring to release the
catch.
6
Remove the 3 nuts of
the compressor.

You can see the rear side
nut when the lower
discharge grille is removed.
Remove the nuts in view
first.
Step
Procedure Points
(R9267)
(R9268)
(R9269)
(R9270)
