SiBE18-821_C Refrigerant Circuit
Refrigerant Circuit 67
Electronic expansion valve
Double pipe heat exchanger
Electronic expansion valve
Filter
Heat exchanger
Service port
Four way valve
High pressure sensor
Solenoid valve
Solenoid valve
Low pressure sensor
Service port
Capillary tube
Capillary tube
Capillary tube
Stop valve (with service port on field piping side
φ
7.9 mm flare connection)
Compressor
High pressure switch
Pressure regulating valve
Filter
Filter
Filter
Filter
Oil
separator
C : 3D052712
(5)
(2)
(A)
(P)
(G)
(N)
(M)
(H)
(D)(D)
(O)
(1)
(4)
(3)
(6)
(7)
(F)
(E)
(T)
S1NPL
S1PH
S1NPH
Accumulator
(8)
