2.1.6 Setting of Vacuuming Mode
In order to perform vacuuming operation at site, fully open the expansion valves of indoor and
outdoor units and turn on some solenoid valves.
[Operating procedure]
(1) In “setting mode 2” with units in stop mode, set the item No.21 (refrigerant recovery /
vacuuming mode) to ON. The respective expansion valve of indoor and outdoor units are
fully opened. “TEST OPERATION” and “UNDER CENTRALIZED CONTROL” are displayed
on the remote controller, and the indoor / outdoor unit operation is prohibited. After setting,
do not cancel “setting mode 2” until completion of Vacuuming operation.
(2) Use the vacuum pump to perform vacuuming operation.
(3) Press the MODE button (BS1) once and reset “setting mode 2”.
2.1.7 Check Operation
To prevent any trouble in the period of installation at site, the system is provided with a test
operation mode enabling check for incorrect wiring, stop valve left in closed, coming out (or
misplacing with suction pipe thermistor) or discharge pipe thermistor and judgment of piping
length, refrigerant overcharging, and learning for the minimum opening degree of electronic
expansion valve.
Unit stopping
Press the TEST button for 5 seconds.
10 seconds to 10 minutes
LED display (H1P~H7P) (
k :ON h :OFF l :BLINK)
hhkhhhh
hlhhhhk
Pressure equalizing
Step 1
20 seconds to 2 minutes
10 minutes
3 minutes
15 minutes
hlhhhkh
Cooling start controlStep 2
hlhhhkk
hlhhkkk
Stability waiting operationStep 3
Refrigerant overcharge judgment
Step 7
• Stop valve close check
• Wrong wiring check
• Piping length check
hlhhkhh
hlhhkhk
hlhhkkh
Judgment function
Step 4~6
5 seconds
hlhkhhk
hlhkhkh
Pump-down residual operation
Step 8
2 minutes
Standby for restarting
Completion
Step 9
(R12957)
