SiBE18-821_C RA Indoor Unit
Operation Manual 229
FTXS60/71FV1B
îš„ Remote Controller
1
2
5
6
9
11
<
ARC433B70, 71
>
3
4
7
8
10
12
16
18
17
15
14
13
1.
Signal transmitter:
•
It sends signals to the indoor unit.
2. Display:
•
It displays the current settings.
(In this illustration, each section is shown with all
its displays ON for the purpose of explanation.)
3.
HOME LEAVE button:
HOME LEAVE operation
4.
POWERFUL button:
POWERFUL operation
5.
TEMPERATURE adjustment buttons:
•
It changes the temperature setting.
6.
ON/OFF button:
•
Press this button once to start operation.
Press once again to stop it.
7.
MODE selector button:
•
It selects the operation mode.
(AUTO/DRY/COOL/HEAT/FAN)
8.
QUIET button: OUTDOOR UNIT QUIET
operation
9.
FAN setting button:
•
It selects the air flow rate setting.
10.
SENSOR button: INTELLIGENT EYE
operation
11.
SWING button:
•
Flap (Horizontal blade)
12.
SWING button:
•
Louver (Vertical blades)
13.
ON TIMER button
14.
OFF TIMER button
15.
TIMER Setting button:
•
It changes the time setting.
16.
TIMER CANCEL button:
•
It cancels the timer setting.
17.
CLOCK button
18.
RESET button:
•
Restart the unit if it freezes.
•
Use a thin object to push.
