SiBE18-821_C Specifications
Specifications 23
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 V
Model
FCQ35C7VEB FCQ50C7VEB
Cooling Heating Cooling Heating
Rated Capacity 3.5 kW Class 5.0 kW Class
Decoration
Panel
Color Pure White Pure White
Dimensions (H × W × D) 50 × 950 × 950 50 × 950 × 950
Airflow Rates m³/min
H 10.5 12.5 12.5 12.5
L 8.5 10.0 8.5 8.5
Fan
Type Turbo Fan Turbo Fan
Motor Output W 56 56
Speed Steps 2 Steps 2 Steps
Air Filter Resin net with mold resistance Resin net with mold resistance
Dimensions (H × W × D) mm 204 × 840 × 840 204 × 840 × 840
Packaged Dimensions (H × W × D) mm 220 × 882 × 882 220 × 882 × 882
Weight (Mass) kg 19 19
Gross Weight (Gross Mass) kg 24 24
Operation
Sound
H / L dBA 31 / 27 31 / 27
Sound Power H dBA 49 — 49 —
Heat Insulation Foamed polystyrene / Foamed polyethylene Foamed polystyrene / Foamed polyethylene
Piping
Connection
Liquid mm
φ
6.35 (Flare)
φ
6.35 (Flare)
Gas mm
φ
9.52
(Flare)
φ
12.7
(Flare)
Drain mm VP25 (O.D.
φ
32 / I.D.
φ
25) VP25 (O.D.
φ
32 / I.D.
φ
25)
Model
FCQ60C7VEB
Cooling Heating
Rated Capacity 6.0 kW Class
Decoration
Panel
Color Pure White
Dimensions (H × W × D) 50 × 950 × 950
Airflow Rates m³/min
H 13.5 13.5
L8.5 8.5
Fan
Type Turbo Fan
Motor Output W 56
Speed Steps 2 Steps
Air Filter Resin net with mold resistance
Dimensions (H × W × D) mm 204 × 840 × 840
Packaged Dimensions (H × W × D) mm 220 × 882 × 882
Weight (Mass) kg 19
Gross Weight (Gross Mass) kg 24
Operation
Sound
H / L dBA 33 / 28
Sound Power H dBA 51 —
Heat Insulation Foamed polystyrene / Foamed polyethylene
Piping
Connection
Liquid mm
φ
6.35 (Flare)
Gas mm
φ
12.7
(Flare)
Drain mm VP25 (O.D.
φ
32 / I.D.
φ
25)
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
