IM 915-13 • VISION - EXTENDED SIZES 50 www.DaikinApplied.com
AHU Equipment Warranty Registration Form (continued)
13F-4153 (07/18) 3
Select Yes or No. If not applicable to the type of unit, select N/A.
G. Voltage at return fan motor(s): . . . . . . . . . . . . . . . 1–2_____________ V 2–3 _____________ V 1–3 _____________ V
*Fan array units only . . . . . . . . . . . . . . . . . . . . 1–2_____________ V 2–3 _____________ V 1–3 _____________ V
1–2_____________ V 2–3 _____________ V 1–3 _____________ V
1–2_____________ V 2–3 _____________ V 1–3 _____________ V
1–2_____________ V 2–3 _____________ V 1–3 _____________ V
1–2_____________ V 2–3 _____________ V 1–3 _____________ V
H. Return fan motor amp draw(s) per phase: . . . . . . . . . . . . . . L1 _____________ L2 _____________ L3 _____________
*Fan array units only . . . . . . . . . . . . . . . . . . . . . . . . . L1 _____________ L2 _____________ L3 _____________
L1 _____________ L2 _____________ L3 _____________
L1 _____________ L2 _____________ L3 _____________
L1 _____________ L2 _____________ L3 _____________
L1 _____________ L2 _____________ L3 _____________
I. Overload amp setting: . . . . . . . . . . ._______________________________________________________________________
J. What is the return fan rpm? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________
K. Record supply static pressure at unit in inches of H
2
0: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . _____________
L. Record return static pressure at unit (with outside air dampers closed) in inches of H
2
0: . . . . . . . . . . . . . . . _____________
* If additional fans are on the unit, please add them to the space below.
III. DAMPERS
A. Are blades and seals present?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
B. Do damper open smoothly and shut tight?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yes No N/A
