Daintree GE Current WA100-PM User Manual

Installation GuideDaintree
®
Networked Wireless Adapter (WA100-PM)
Theseinstructionsdonotpurporttocoveralldetailsorvariationsinequipmentnortoprovideforeverypossiblecontingencytobemetinconnectionwithinstallation,operation
ormaintenance.Shouldfurtherinformationbedesiredorshouldparticularproblemsarisewhicharenotcoveredsufcientlyforthepurchaser’spurposes,themattershouldbe
referredtoGECurrent,aDaintreecompany.
Questions:
Web: products.gecurrent.com
Phone: 1-866-855-8629
www.gecurrent.com
©2021CurrentLightingSolutions,LLC.Allrightsreserved.GEandtheGEmonogramaretrademarksofthe
GeneralElectricCompanyandareusedunderlicense.Informationprovidedissubjecttochangewithoutnotice.
Allvaluesaredesignortypicalvalueswhenmeasuredunderlaboratoryconditions.
DT113(Rev.04/28/2021
CAUTION
RISK OF EXPOSURE IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSAL OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
WFA100-PM
Input Voltage 120-277VAC,50-60Hz
Switched Output  15Adriver/incandescent@120-277VAC
Relay 1hp@120-230VAC(switchedtoHot/Active)
Low Voltage 24VDC;75mAmaximum
Output
Low Voltage Intel
®
Atom™ProcessorE3805
Wiring
Memory and 22AWG,600V,UL1015,plenumratedMax. 
Storage recommended length of up to 100’ (30m)
Analog Dimming 0-10VDC,5mAmax(sinkorsource),upto
  10typical0.5mAsinkingdrivers/ballasts* 
Analog Input Photosensor 0-10VDC
Digital Input (2) Activehigh.Occupancysensor,
  DimUp/Down(switchmode)
Digital Output LSD(lowsidedriver)auxrelaycontrol,
  75mAmaximum(includingattached
sensors)
Radio Properties 2.4GHz,+8dBm,Rangedependent
  onRFpropagationvariablessuch
  asmetalobstacles
Operating Indoor,drylocation
Environment -4°to149°F(-20°to65°C)
Compliance CSAcertied,plenumrated,
  FCCPart15,CAIC
Mounting 1/2”knockout,screwtab,optional 
  mountingbracketsupplied
Dimensions 9.4”Lx1.7”Wx1.18”H
10.1”Lx1.7”Wx1.18”Hwith
  mountingbracket
Specications
*“Driver”referencesinclude“ballasts”unlessotherwisenoted.
