Daintree GE Current WA100-PM User Manual

Installation GuideDaintree
®
Networked Wireless Adapter (WA100-PM)
12
Figure 18: Secure unused wires
Figure 19: Mounting in driver channel
Figure 20: Mounting with the
included bracket
Figure 21: Mounting external to the top
of a suspended xture
Securing Low Voltage Wires
1.MakesuretheunitisNOTpowered.
2. Cuttheunusedlowvoltagewiresapproximatelyve
 inchesfromwheretheyexittheWA100-PMbody.
TheWA100-PMisdesignedsothatitcanbemountedinavariety
ofways.Dependingontheconstructionofthextureanditsability
topropagateradiosignals,itcanbemountedinsidethexturein
theballast/driverchannel.Aprintedbarcodelabelwiththefull
IEEEaddressisincludedwiththeWA100-PM.Afxthislabeltothe
outsideofthexture.Chooseastandardlocationsothatwhen
someonelooksforxturescontainingaWA100-PM,theywill
easilyndit.
UsingtheMountingBracket
ThemountingbracketincludedwiththeWA100-PMandshownin
theillustrationbelowprovidesascrewmountingalternative.
Thebrackethasaslotthatallowswirestoremainconnectedasyou
snapthebracketontotheWA100-PMnipple.TheWA100-PM
canbesecuredattheotherendusingtheintegralscrewtab.
Alternatively,itcanbemountedexternallytoajunctionbox,
enclosure,orxturehousingthrough
a1/2”knockout.
3.Isolatetheendofeachwireusingawirenut,shrinktubing,or 
equivalent.
4. Wrap the unused low voltage wires around the side of the
 adapterinabunch,andsecuretheminplaceusingawhiteor 
 clearcabletie.
8
9
Trimming and Dressing
Mounting
