Installation GuideDaintree
®
Networked Wireless Adapter (WA100-PM)
5
Figure 5: On/Off (non-dimming) Light Fixtures
ThiscongurationallowstheWA100-PMtoprovideautomatic
On/Offswitchingoflightxtures.
Figure 6: On/Off (non-dimming) Light Fixture(s), Occupancy
Sensor conguration
ThiscongurationallowstheWA100-PMtoprovideautomatic
On/Offswitchingbasedonoccupancy.Setoccupancysensor
for minimum time delay.
7
Wiring Continued
Perform Installation Test Suite 1
DIP Switches
DriverType:
On/Off+0-10V
dimming
WiredSensor:
None
On
1 2 3 4 5 6
(#4 ON)
Perform Installation Test Suite 2
DIP Switches
DriverType:
On/Off
(no dimming)
WiredSensor:
Occupancy
On
1 2 3 4 5 6
(#4, 5 ON)
OFF
ON
OFF
ON
