Installation GuideDaintree
®
Networked Wireless Fixture Adapter (WFA100-SN)
6
Figure 10: Bypass WFA100 switched power and 0-10V dimming control during power failure
Figure 5: On/Off (non-dimming) Ballasts
3
Wiring Continued
Inthewiringdiagrambelow,theWFA100-SNispoweredby
the Emergency power circuit.
Regularpowerisbroughtintothexturefromanadjacent
xtureandconnectstotheRRU-X-UM.
WhileRegularpowerissuppliedtotheRRU-X-UMthe
WFA100-SNprovidesswitchedOn/Offpowertothe
xtureandcontrolsdimming.
WhentheRRU-X-UMsenseslossofRegularpower,itpasses
Emergencypowerdirectlytothextureanddisconnectsthe
WFA100-SN switched output. Loss of Regular power to the
RRU-X-UMdisablestheWFA100-SNdimmingcontroland
thexturewilloperateatmaximumoutput.
