REAR AREA ASSEMBLY
3/16/2021
11/13/2020
SHEET 2 OF 2SCALE: 1:18
REV
SHEET TITLE:
A
SIZE
4400445 800W REAR AREA ASSEMBLY
F O R P A R T S , C A L L 1 . 8 0 0 . 3 4 2 . 7 4 9 8
w w w . D a l t o n A g . c o m
CHECKED BY
BOM
A
PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
DRAWN BY
CONFIG.
PRINT DATE
COMMENTS:
DWG:
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
DALTON AG. ANY REPRODUCTION IN
PART OR AS A WHOLE WITHOUT THE
WRITTEN PERMISSION OF DALTON AG IS
Jeremiah Jondle
ITEM NO. PART NUMBER QTY.
1
1000646 BEARING 1.25 BORE 1
2
4421684 DIVIDER, WELDMENT, WIDE SPREAD 1
3
1001390 TROUGH EXTENSION BACK 1
4
4410815-L SPINNER ASSEMBLY, LH 1
5
4421661 SPINNER DISC, WELDMENT, LH 1
6
4421685 DISC CAP WELMENTS L.H. 1
7
4431277 SPINNER BLADE, 11 INCH 3
8
4410815-R SPINNER ASSEMBLY, RH 1
9
1003709-VR SPINNER HUB,VARIABLE RATE,
MACHINED
1
10
4421662 SPINNER DISC, WELDMENT, RH 1
11
158054 FLAT WASHER, .3125, SS 32
12
158053 LOCK WASHER, .3125, SS 16
13
150007 NUT, .3125 NC, SS 16
14
151615 BOLT, .3125 X .75 SS 12
15
4441174 GEAR BOX SET, 26.375 CENTERLINE 1
16
4421647 REAR BUMPER, RC, WIDE SPREAD 1
17
4432469 PARTER PLATE, WIDE SPREAD 1
18
1000838 DRIVE SPROCKET ASSEMBLY 1
19
1000684 CAST SPROCKET, MACHINED 1
20
158035 ROLL PIN .3125 X 3.5 2
21
1000644 SPROCKET SHAFT 1
22
151834 BOLT .375 X .75 NC, SS 14
23
150214 FLAT WASHER, .375 SS 36
24
150248 LOCK WASHER, .375, SS 26
25
150046 NUT, .375 NC, SS 18
26
1000507 SPROCKET 50B36 1
27
4441075 1.25 PIPE CAP 2
28
640012 SPROCKET, 50B12 1
29
150225 LOCK WASHER, .75, SS 2
30
150013 NUT, .75 NC 2
31
151815 BOLT, .375 X 1.25 NC, SS 12
32
641653 KEY, .25 X .25 X 1.25 2
33
4432166-86 CHAIN, SS #50 CHAIN, 86 PITCH w
CONNECTOR (PWM DRIVE)
1
34
4432166-108 CHAIN, SS #50 CHAIN, 108 PITCH w
CONNECTOR (GROUND DRIVE)
1
35
4421686 DISC CAP WELDMENT R. H.
1
