Danbit H.264 DVR - Back Panel

11
2.2. BACK PANEL
NO.
LABEL
OPERATION
1
AUDIO OUT
Audio Output
2
VIDEO OUT
(VGA)
LCD monitor connector
3
ETHERNET
RJ-45 connector
4
AUDIO IN
Audio input
5
POWER
Power adapter (AC 12V/5A) connector
6
VIDEO IN
BNC video input
7
DI / DO
2 alarm in / RS485 / 1 relay out
8
VIDEO OUT
(HDMI)
HDMI video output
