Danbit H.264 DVR - Specifications

1.2. SPECIFICATIONS
MODEL
9 CH Hybrid DVR
System
OS
Embedded Linux
Connectors
Ethernet
RJ-45, 10/100 Mbps x1
Video
output
VGA / HDMI / BNC
USB
Front : USB 2.0 x1
Back: USB 2.0 x1
Power
DC-12V
Video and Audio
IP Camera Video Input
Max 3 channels
IP Camera Resolution
Up to 5 Megapixel
IP Camera Frame rate
Up to 30 FPS @ NTSC per CH
IP Camera Bit rate
Single CH: up to 8Mbps
Total: up to 24Mbps
Analog Video Input
Max 8 channels
Analog
Resolution
960H
960 x 480 (NTSC); 960 × 576 (PAL)
D1
720 x 480 (NTSC); 720 × 576 (PAL)
Analog Live-time Display
Rate
8 x 30 Frame /sec (NTSC)
8 x 25 Frame /sec (PAL)
Analog Audio Input
4 channels
Hybrid DVR Functions
Camera Name
Max. 20 characters
Screen Split Control
1, 4, 9
Image Control
Contrast / Brightness / Saturation / Hue
Recording mode
Manual / Schedule / Alarm
Single Channel Recording
Selectable in Alarm-trigger mode
