23
(5) After you set the screen pattern, use the fisheye channel list to select one of
the sub screens. (just as the circle on the picture above). The selected sub
screen will be indicated in a red frame.
(6) For the selected sub screen, use the 4-direction arrows and the “+” (zoom
in) ”-” (zoom out) icon for E-PTZ control.
(7) Control Mode: Select the E-PTZ moving mode, step by step or continuous.
(8) The AutoPan, Stop, and Patrol buttons are invalid here if the fisheye camera
doesn’t support those function.
F. DISK INFORMATION
Displays the disk information on live mode.
G. DIGITAL ZOOM
On live full screen mode, left-click to select a zoom-in or zoom-out range for the
image. The users can right-click for disabling this function. (NOTE: the image can
be zoom-in to max. 16x.)
H. AUDIO VOLUME
Press this button, and the audio volume control board will pop up.
