Danby DPA100E1BDB - Installation in a Sliding Sash Window

Foam seal A
(adhesive type)
Fig.13
Fig.14
Window
Panel
Fig.15
Foam
Seal
Fig.16
72 cm -2.07 m
(28.3 - 81.5 in.)
11
Installation Instructions
INSTALLATION IN A
SLIDING SASH
WINDOW
1. Measure the adhesive foam seal to fi t the windowsill. Cut the foam seal (adhe-
sive type) to the proper length and attach it to the window frame. See fi g. 13.
2. Adjust the length of the window slider kit according to the height of the window,
shorten the adjustable window kit if the height of the window slider is less than
the opening. Open the window sash and place the window slider kit on the
windowsill. See fi g. 14.
3. Cut the foam seal (adhesive type) to the proper length and attach it to the top
of the window. Shown in fi g. 15.
4. Close the sliding sash securely against the window.
5. Cut the foam seal to an appropriate length and seal the open gap between the
top window sash and outer window sash. Shown in fi g. 16.
52 cm -
1.52 m
