Installation Instructions
EXHAUST HOSE
INSTALLATION
The exhaust hose and adaptor must be installed or removed in accordance with the
usage mode.
COOL, DRY or AUTO mode Install
FAN Remove
1. Install the window exhaust adaptor onto the exhaust hose as shown in Fig. A.
Refer to the previous pages for window kit installation.
2. Insert the exhaust hose into the rear air outlet opening Fig. A.
• The hose can be compressed or extended moderately according to the installation
requirement, but it is desirable to keep the hose length to a minimum.
IMPORTANT
DO NOT OVER BEND THE HOSE
