Installation Instructions
WATER DRAINAGE
• During DRY modes, remove the drain plug from the back of the unit,
attach the drain hose to the hole. Place the open end of the hose directly
over the drain area in your basement fl oor. Please refer to Fig. 5.
• For small amounts of water, remove the drain plug and place a pan under
the drain outlet as shown in Fig. 4.
NOTE: Make sure the hose is secure so there are no leaks. Direct the hose
toward the drain, making sure that there are no kinks that will stop the water
from fl owing. Place the end of the hose into the drain and make sure the end
of the hose is down to let the water fl ow smoothly. (see Fig. 6). Never raise it.
(See Fig 7).
NOTE: When operating or draining water, always protect carpeting or fl oors
from possible water spillage.
NOTE: Be sure to reinstall the bottom drain plug before using the unit.
NOTE: Drain hose not included.
Drain outlet
Drain plug
Drain pan
Drain plug
Drain outlet
Drain hose
