11 AIRLAB MASTER BACK PANEL WIRING
EXTERN IN
Connector type is Cinch. Unbalanced, level = 0 dBu 10 kOhm
AIR IN
Connector type is Cinch. Unbalanced, level = 0 dBu 10 kOhm
GUEST OUT STEREO
Connector type: Jack Tip = Left
Level: +20 dBu/330 Ohm Ring = Right
Sleeve = Ground
ANNOUNCER OUT STEREO
Connector type: Jack Tip = Left
Level: +20 dBu/330 Ohm Ring = Right
Sleeve = Ground
ON AIR SIGNALING 1
Connector type: Jack REED RELAY MAX VOLTAGE 24 VOLT/50 mA
Tip = Center contact
Ring = Normally open
Sleeve = Normally closed
ON AIR SIGNALING 2
Connector type: Jack REED RELAY MAX VOLTAGE 24 VOLT/50 mA
Tip = Center contact
Ring = Normally open
Sleeve = Normally close
STUDIO OUT
Connector type: Cinch, Unbalanced
Level: +6dBu / 47 Ohm
SUB OUTPUTS
Connector type: Male XLR Pin1 = ground
Level: +6dBu Pin2 = in phase
Pin3 = out of phase
